Inline Flexo Film Press (1-15 Colors)
Parameter Configuration
| Specification | 14.5"(370) | 16.5"（420） | 20.5"(520) | 25.5"(650) |
| Max web width | 370mm | 430mm | 530mm | 660mm |
| Max pringting width | 350mm | 420mm | 520mm | 650mm |
| Max die-cutting width | 350mm | 420mm | 520mm | 650mm |
| Printing repeat length | 152-610mm | 152-610mm
| 152-610mm
| 152-610mm
|
| Die-cutting repeat length | 290-610mm | 290-610mm
| 290-610mm
| 290-610mm
|
| Max unwinding diameter | 1016mm | 1016mm | 1016mm
| 1016mm
|
| Max rewinding diameter | 1016mm/762mm | 1016mm/762mm | 1016mm/762mm
| 1016mm/762mm
|
| Gearing | 1/8cp | 1/8cp | 1/8cp | 1/8cp |
| Max printing speed | Single Servo Motor Driven/Dual Servo Motor Driven:200m/min |
| Drying mode | Hot-air Drying/IR drying/UV drying |
| Applicable ink | Eco-friendly water-based ink/UV ink/Solvent ink
|
