Feature
Unwind and Rewind adopts magnetic break and magnetic clutch for automatic tension control, controller Mitsubishi.
Ceramic anilox for ink transfer.
Adopts 360 degree registration.
IR and UV dryer available.
Main motor controlled by inverter.
Options includes Lamination, Foil stamping, UV varnishing, Rotary die cutting, Sheeting etc.
| Model | 320-5D |
| Printing Speed | 5-60m/min |
| Printing Color | 5 Colours |
| Max. Web Width | 320mm |
| Max. Printing Width | 310mm |
| Max. Unwinding Diameter | 600mm |
| Max. Rewinding Diameter | 550mm |
| Printing Girth | 175-380mm |
| Precision Of Chromatography | 士0.10mm |
| Dimensions (K*W*H) | 2100*1100*2600mm |
| Machine Weight | About 2600 kg |
