Machine direction | From the left to the right |
Print units | 1~12 colors |
Max film width | 600mm~1350mm |
Max.machine speed | 270m/min (Φ300mm plate cylinder dia.) |
Max. print speed | 250m/min (Φ300mm Plate cylinder dia.) |
Max. print repeat length | 630-1400mm |
Color register accuracy | Circumferential ±0.1mm (automatic register) Lateral ± 0.1mm (manual control) |
Unwind web-roll dia | Φ800mm |
Rewind web-roll dia. | Φ800mm |
Tension range | 5-60kg (full load) |
Tension accuracy | ±0.5kg (breadth accuracy) |
Paper core dia | φ76 mm (inner)×φ92mm (outer) |
Air source | 0.6Mpa (6 bar, approx.0.5m³/h) |
Impression | 900kg(full-breadth load) |
Doctor dance | ±5mm |
Drying method (At choice) | Steam (5bar, 80℃, approx.500m3/h) (user provides the heat source) |
Cooling water | 8T/h (0.3MPa) (30℃) |
Print motor power | 11.0 KW Servo motor |
Total machine power | Approx. 210 KW |
